ASUS TUF GAMING A620AM-Plus AM5 Motherboard
Form factor: microATX
Socket: AMD AM5
Chipset: AMD A620
Memory: DIMM x 4 / Max RAM: 128 GB DDR4
3 year guarantee
Product code: 722832

The ASUS TUF Gaming A620AM-Plus mootherboard packs plenty of power into a Micro-ATX design. It's ready for AMD 9000 Series processors, so you've got a solid foundation for your next build. You can pair it with up to 128 GB of DDR5 RAM for smooth gaming and multitasking. With PCIe 4.0 and PCIe 3.0 support, your graphics card and SSD can run at full speed. Plus, TUF gaming-grade components keep it reliable and durable for gaming and everyday use.

Good to know

  • AEMP technology automatically optimises memory settings for better performance
  • Armoury Crate manages cooling, performance settings and RGB lighting
  • Large onboard heatsinks help keep temperatures under control
  • AIO Pump header supports liquid cooling for your CPU
  • Aura Sync matches RGB lighting across compatible devices
  • 2.5 Gb Ethernet connection

Technical specifications for ASUS TUF GAMING A620AM-Plus AM5 Motherboard

OVERVIEW

Form factor
microATX
Chipset
AMD A620
Socket
AMD AM5
Processor models supported
AMD Ryzen 9000 / 8000 / 7000 Series desktop processors
Memory slots
4 x DIMM (Max RAM: 128 GB)
Memory standard
DDR5
Cooling features
- Fan cooling
- Heatsink cooling
Operating systems supported
- Windows 11
- Windows 10

EXTERNAL CONNECTIVITY

Video output
- HDMI x 1
- DisplayPort x 1
LAN
Realtek 2.5Gb Ethernet x 1
Audio
- 3.5 mm jack x 3
- Realtek 7.1 HD
USB
- USB Type-C x 1
- USB 3.0 x 2
- USB 2.0 x 2
Other external connections
BIOS FlashBack button x 1

INTERNAL CONNECTIVITY

BIOS
UEFI AMI BIOS
Expansion slots
- PCIe 4.0 (x16 slot) x 1
- PCIe 3.0 (x1 slot) x 2
Storage slots
- SATA x 4 (6 GB/s)
- M.2 x 2
Cooling
- 4-pin CPU Fan header x 1
- 4-pin Chassis fan × 2
Case
- Power LED
- HDD LED
- Front panel I/O headers
Buttons
- BIOS FlashBack
- Clear CMOS
Power
- 24-pin Main Power connector x 1
- 8-pin +12V CPU Power connector x 1
Sensors
- Thermal sensor
- Fan speed sensors
Other internal connections
- RGB header x1
- Addressable Gen 2 header x2
- TPM header

GENERAL

Box contents
- ASUS TUF GAMING A620AM-PLUS AM5 Motherboard
- SATA cables x2
- M.2 screws
- I/O shield
- User manual
Weight
820 g
Manufacturer’s guarantee
3 years
Dimensions
275 x 275 x 45 mm (H x W x D)
Colour
Black
